50m Granite Quarry Wire From Romatools

Overview Product Description 11.5mm diamond wire for hard granite quarry cutting mine quarring from romatools Applicatio

Send to us

Overview

Basic Info.

OEM	Available
Feature	Fast Cutting, Long Life, Stable Quality
Fixture	Rubber
Certification	Reach
Transport Package	Plastic Wrap + Export Carton + Wooden Pallet
Specification	11.5mm x 40bpm
Trademark	ROMATOOLS
Origin	China
HS Code	8202991000
Production Capacity	60000meters/Year

Product Description

11.5mm diamond wire for hard granite quarry cutting mine quarring from romatools
Application: Granite Quarry
Feature: Fast Cutting, Long Life, Stable Quality

We can provide different bond designs and beads sizes according to the stone types!

Romatools Diamond Wire Usage InstructionPlease read the instruction before using the wire.

Wire Connection• Plastic reinforced wire should be twisted 1.5-2 rounds/meter• Rubber reinforced wire should be twisted 2-3 rounds/meter.• Use correct crimping die and ferrule.

Wire Operation

• When new wire starts to run, use less water and less wire speed to sharpen the wire until diamonds are coming out. Afterwards, the wire speed for plastic reinforced wire is suggested to be 26-31 meter/second; the wire speed for rubber reinforced wire is suggested to be 28-36 meter/second, and make sure the wire is cooled down with proper cooling water. For hard stone, wire speed should be reduced accordingly; for soft stone, wire speed should be increased accordingly.

Precaution• Safety: It is prohibited to stand close to running diamond wire to avoid hurting people in case wire breakage.• Storage: avoid tensioning the plastic reinforced wire while not using; avoid rubber reinforced wire being exposed to sunshine for too long and avoid wire being contaminated with oil.• Side Wearing: increase twisting number appropriately.

Application	Diameter	Bead/Meter	Manufacture Tech	Fixture	Line Speed	Cutting Spead	Life
Application	(mm)	Bead/Meter	Manufacture Tech	Fixture	m/s	m2/h	m2/m
Granite	6.3	37	Sintered	Plastic	Hard: 20-24Medium: 22-26 Soft: 24-28	Hard: 0.4-0.6Medium: 0.8-1.2 Soft: 1.2-1.8	Hard: 12-15Medium: 20-25 Soft: 25-30
	7.3	37
	8.0	37
	8.8	37
	10.5	37
	11.5	40		Rubber	18-22,22-25,25-30	2-4,4-8,8-15	7-9,8-15,15-25
Marble	6.3	37	Sintered	Plastic	Hard: 28-32Medium: 32-35 Soft: 30-35	Hard: 1-2Medium: 2-3 Soft: 3-4	Hard: 20-30Medium: 30-60 Soft: 60-80
	7.3	37
	8.0	37
	8.8	37
	10.5	37
	11.0	28		Spring	20-30,20-35,25-35	4-9,8-15,10-20	15-25,15-35,20-50
Reinforced Concrete	11.5	40	Sintered	Rubber+Spring	Concrete Strength Grade ≤ 50Mpa Diameter of the Steel Bar ≤ 50mm		1.0-3.0
Steel (Metal)	10.5	44	Vacuum Brazed	Rubber+Spring	High Strength Reinforced ConcreteEmergency Rescue, Very Fast Cutting		1.0-2.0
Note: Other specifications are available upon request!
